C200 HD. This is SSL.
Sound Creators Inc, Japan Fox, USA
With demand for television programmes and DVD content on the
increase, SCi felt it was time to upgrade its main vehicle so that
it was better placed to cope with 5.1 surround sound
productions. The C200 HD was an ideal console choice because
it is very compact and can be tailored to fit into small spaces
such as a mobile studio.
The Fox on-air promotion department is a high-volume
production group that creates hundreds of promos per week.
Their C200s are integrated with hard disk editing systems to
provide a truly re-settable random access environment.
Reliability and efficiency are essential to producing this volume
of production output.
Physical and Environmental Specification
Max Height 1124mm (44.25")
Max Width (see diagram)
Each channel bay adds 334mm (13.15")
End trim adds 128mm (5.04")
Max Depth 1144mm (45.04")
Height Adjustment ±22.5mm (±0.9")
Weight (48 channels) ~354kg (~780lbs)
Each (inc. centre) adds ~40kg (~88lbs)
Legs add ~33kg (~73lbs)
Power (40ch with 100-240V AC) < 1.2kW
Continuous (dependent on frame size)
Cooling Method Convection (silent)
